Delfield GUF32P-S 32″ W Undercounter Freezer w/ (1) Section & (1) Door, 115v

The one-section cabinet in the Delfield GUF32P-S Coolscapes undercounter freezer has an epoxy-coated shelf. While the door opens to a 180-degree angle, its hinges prevent it from being left open at less than 90 degrees. After a 90-degree-angled opening, the door stays open so employees can stock the cabinet. A magnetic gasket in the door seals in cold air, and the door has a built-in handle. To reduce heat transfer, high-density polyurethane insulation is foamed in place in the cabinet.

Depending on the application, the temperature in this Delfield GUF32P-S one-section undercounter freezer can be set between -5 and 0 degrees Fahrenheit on the electronic controller. Reducing compressor cycling to lengthen component lifespan and save energy, the control system cuts pull-down times after loading. So clearances at the top and sides are not required, the refrigeration system is rear mounted and has a front-breathing design.

Product Details

• 8-cu.-ft. interior space
• 1 section
• Gray epoxy-coated shelf
• Stainless steel door can be field reversed to fit different layouts
• Door has a 180-degree opening
• Smart door hinge has a self-closing feature at less than 90 degrees
• Door stays open past 90 degrees
• Replaceable heater in the door opening
• Magnetic door gasket is removable
• Built-in door handle
• High-density, foamed-in-place polyurethane insulates the cabinet
• 5-in. casters (2 braking)

Refrigeration System

• Electronic temperature control is designed to improve pull-down times for reduced compressor cycling
• Temperature holding range: -5 to 0 degrees F
• Rear digital temperature display
• GreenGenius R290 hydrocarbon refrigerant
• Thermostatic expansion valve meters refrigerant based on temperature level
• Adaptive defrost prevents ice buildup on the evaporator
• Hot gas condensate system
• Rear-mounted design
• Front-breathing airflow eliminates clearance requirements on the top and sides

Durable Construction

• Gray-coated interior sides
• Anodized aluminum interior bottom
• Stainless steel exterior top and front
• Aluminum exterior sides
• Galvanized exterior back and bottom

Dimensions & Utilities

• Interior: 27.90 in. W x 19.90 in. D x 22.20 in. H
• Overall: 32 in. W x 31.59 in. D x 36 in. H
• 2.60 A, 2.17 kW, ¹/₅ HP
• 115 V/60 Hz/1 ph, 8-ft. cord with a NEMA 5-15P plug

Coolscapes Undercounter/Worktable Freezer, one-section, 32″ W, 8.0 cubic feet, (1) stainless steel door, (1) gray epoxy coated shelf, stainless steel top and front, aluminum sides, galvanized back and bottom, gray coated aluminum interior sides & anodized aluminum bottom, 5″ casters (2 locking, 2 non-locking), rear-mounted refrigeration system, GreenGenius R290 Hydrocarbon refrigerant, 115v/60/1, 2.6 amps, 8′ cord, NEMA 5-15P, 1/3 HP, UL, cUL, NSF, ENERGY STAR

Note: Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
