Delfield N8681P Drop-In Hot/Cold Food Well w/ (6) Full Size Pan Capacity, 120-240v/1ph

$10,352.16

  • Capacity: (6) 12-in. x 20-in. pans
  • Can be installed into 80.75-in. x 25-in. counter cutout
  • Stainless steel top and interior and galvanized steel exterior
  • Adjustable pan supports
  • Adaptor bars
  • Stainless steel immersion heaters (for wet heating only)
  • Remote control panel with 3-way hot/cold/off power switch
  • Thermostat for heating
  • Electronic temperature control
  • Insulated with high-density polyurethane foam
  • 1-in. stainless steel drain and screen
  • Push-in flange gasket
  • Stainless steel louver included
  • 1,361-BTU heat transfer capacity
SKU: DelfieldN8681P Category:

Description

Delfield N8681P Description

Because an immersion heater is built into the bottom of the Delfield N8681P drop-in hot/cold food well and a self-contained condenser is located underneath the unit, it can heat or cool prepared foods as menu items change. The heater and condenser are both controlled by a three-way hot/cold/off remote control panel power switch, and operators can adjust heater temperatures with the thermostat. If heater temperatures rise above the programmed range, the high-limit safety switch turns the heater off automatically and illuminates a control panel pilot light. To ensure temperatures are preserved in warm or cool environments, the unit is lined with high-density polyurethane foam.

The Delfield N8681P drop-in combination food well measures 81.75 inches wide by 26 inches deep by 26.24 inches high and can be installed into an 80.75-inch-wide by 25-inch-deep counter cutout. While its top and interior are corrosion-resistant stainless steel, the exterior has a galvanized steel construction for durability. Ideal for buffets with frequent menu changes, the well accommodates six 12-inch by 20-inch food pans that can be raised or lowered with pan supports. To create defined barriers between pans, this unit comes with adaptor bars.

Product Details

  • Capacity: (6) 12-in. x 20-in. pans
  • Can be installed into 80.75-in. x 25-in. counter cutout
  • Stainless steel top and interior and galvanized steel exterior
  • Adjustable pan supports
  • Adaptor bars
  • Stainless steel immersion heaters (for wet heating only)
  • Remote control panel with 3-way hot/cold/off power switch
  • Thermostat for heating
  • Electronic temperature control
  • Insulated with high-density polyurethane foam
  • 1-in. stainless steel drain and screen
  • Push-in flange gasket
  • Stainless steel louver included
  • 1,361-BTU heat transfer capacity

Dimensions & Utilities

  • 81.75 in. W x 26 in. D x 26.24 in. H
  • 42 A, 1/3 HP
  • 120-240 V/60 Hz/1 ph

Drop-In Hot/Cold Food Well, 81-3/4″, 6-pan size for 12″ x 20″ pans, 8″ deep single tank with drain, remote control panel with single temperature control & three-way toggle switch, stainless steel top & well, galvanized steel exterior housing, self-contained refrigeration, R290 refrigerant, 1/3 HP, (80-3/4″ x 25″ cutout required), cUL, UL, NSF
