Vulcan HEG48E 48″ Electric Griddle w/ Thermostatic Controls – 1/2″ Steel Plate, 240v/3ph

$6,017.00

  • Part of the HEG-E series
  • Stainless steel construction
  • Temperature range: 200-450 degrees F
  • 0.5-in.-thick steel plate
  • 4 snap-action thermostats with cycling lights
  • Heats in 12-in. sections
  • 2 solid, sheathed, tubular incoloy heating elements
  • 4 chrome thermostat knob guards
  • (4) 4-in.-high adjustable legs
  • 4-in.-high rear splash guard and 2 tapered side splash guards
  • 3.5-in.-wide front grease trough
  • 1.5-gal. grease drawer
  • Side and rear clearance: 1 in.
  • Bottom clearance: 4 in.

Plant Based Pros is an Authorized Retailer of Vulcan products.
Items purchased from Plant Based Pros are:

  • Brand new and in original packaging.
  • Covered by the full manufacturer warranty.
  • Qualified for manufacturer service and support.
  • Questions? Call (800) 522-0517
SKU: VulcanHEG48E Category:

Description

Vulcan HEG48E

The Vulcan HEG48E HEG-E Series heavy-duty electric griddle fits on a countertop for versatile cooking. Able to adjust on its 4-inch-tall legs, the griddle is made of durable stainless steel to thrive in humid, bustling kitchen environments. Its 48-inch-wide by 24-inch-deep griddle plate has a 0.5-inch-thick steel cooking surface that gets as hot as 450 degrees Fahrenheit. Snap-action thermostatic controls line the front of the griddle, separately heating four 12-inch-wide sections for independent cooking results. This griddle’s plate is heated with two incoloy heating elements, and a cycling light is located beside each thermostat to alert the operator when the surface is hot.

Grease stays contained on top of the Vulcan HEG48E commercial griddle with a 4-inch-tall rear splash guard and two tapered side splash guards. Excess fat and oil drain into a grease trough located at the front of the griddle, and the grease drawer-located below the trough-collects as much as 1.5 gallons of grease. The griddle’s smooth surface is easy to wipe down, making it a low-maintenance, long-lasting item.

Product Details

  • Part of the HEG-E series
  • Stainless steel construction
  • Temperature range: 200-450 degrees F
  • 0.5-in.-thick steel plate
  • 4 snap-action thermostats with cycling lights
  • Heats in 12-in. sections
  • 2 solid, sheathed, tubular incoloy heating elements
  • 4 chrome thermostat knob guards
  • (4) 4-in.-high adjustable legs
  • 4-in.-high rear splash guard and 2 tapered side splash guards
  • 3.5-in.-wide front grease trough
  • 1.5-gal. grease drawer
  • Side and rear clearance: 1 in.
  • Bottom clearance: 4 in.

Dimensions & Utilities

  • Griddle plate: 48 in. W x 24 in. D
  • Overall: 48 in. W x 31.5 in. D x 15.3 in. H
  • 39-58.5 A, 21.6 kW
  • 240 V/50-60 Hz/3 ph

Heavy Duty Griddle, electric, countertop, 48″ W x 24″ D cooking surface, 1/2″ thick polished steel griddle plate, bottom mounted snap action thermostat every 12″, low profile, stainless steel front, sides, front top ledge with “Cool Bullnose”, front grease trough, 4″ back & tapered side splashes, 4″ adjustable legs, cCSAus, NSF
